| Nombre | Especificaciones Técnicas | Unidad |
| CAPACITY | ||
| MAX SWING DIA. OVER BED | Ø660 | mm |
| MAX. SWING DIA. OVER CROSS SLIDE | Ø420 | mm |
| MAX. SWING DIA. OVER GAP | Ø870 | mm |
| EFFECTIVE LENGTH IN GAP | 240 | mm |
| BED WIDTH | 390 | mm |
| CENTER DISTANCE | 1000 | mm |
| SPINDLE | ||
| SPINDLE HOLE DIAMETER | Ø105 | mm |
| TAPER OF SPINDLE BORE | Metric 113mm 1:20 | |
| TYPE OF SPINDLE NOSE | CAMLOCK D1-8 | |
| FEED AND THREADS | ||
| SPINDLE SPEEDS | 2 pasos; 30-1600 | RPM |
| MAX. TRAVEL OF UPPER TOOLPOST | 145 | mm |
| MAX. TRAVEL OF LOWER TOOLPOST | 310 | mm |
| TOOL SECTION | 25 x 25 | mm |
| X-AXIS FEEDRATE | 60 ; 1.9 | Hz ; m/min |
| Z-AXIS FEEDRATE | 60 ; 4.5 | Hz ; m/min |
| X-AXIS FEEDS | 65 clases 0.027-1.07 | mm/r |
| Z-AXIS FEEDS | 65 clases 0.063-2.52 | mm/r |
| METRIC THREADS | 22 clases 1-14 | mm |
| INCH THREADS | 25 clases 20-2 | t.p.i. |
| MODULE THREADS | 18 clases 0.5-7 | π mm |
| DIAMETRIC PITCH THREADS | 24 clases 56-4 | DP |
| TAILSTOCK | ||
| SPINDLE DIAMETER | Ø75 | mm |
| SPINDLE TRAVEL | 150 | mm |
| SPINDLE TAPER | Morse No. 5 | |
| MOTOR | ||
| MAIN MOTOR POWER | 10, (7.5 kW), Voltaje Dual 440, 3 trifásico. | HP / Kw / Ph |
| RAPID TRAVERSE MOTOR POWER | 0.375 | kW |
| COOLANT PUMP MOTOR POWER | 0.12 | kW |
| DIMENSIONS | ||
| LENGTH | 2630 | mm |
| WIDTH | 1000 | mm |
| HEIGHT | 1450 | mm |
| WEIGHT | 2500 | kg |
| ACCESORIOS ESTÁNDAR | ||
| 3 JAW CHUCK | ||
| 4 JAW CHUCK | ||
| “CE” CERTIFICATE ELECTRIC COMPONENTS | ||
| FOLLOW REST AND STEADY REST | ||
| DRIVE PLATE | ||
| COOLING AND LIGHTING SYSTEM | ||
| FOOT BRAKE | ||
| TOOL BOX | ||
