| Nombre | Especificaciones Técnicas | Unidad |
| CAPACITIES | ||
| SWIG OVER BED | 1000 | mm |
| SWING OVER GAP | 1200 | mm |
| LOADING CAPACITY | 3.5T | |
| SWING OVER CROSS SLIDE | 680 | mm |
| CENTER DISTACE | 1,1.5,2,3,4,5,6,8,10,12 | m |
| BED WIDTH | 600 | mm |
| HEADSTOCK | ||
| SPINDLE HOLE | 105 | mm |
| SPINDLE TAPER | ɸ120mm taper 1:20 | |
| SPINDLE SPEEDS (NUMBER) | 7.5 - 1000 | r/min |
| FEED BOX | ||
| METRIC THREADS RANGE | 1 - 240 (52 kinds) | mm |
| INCHTHREADS RANGE | 1 - 14 (26 kinds) | in |
| WORM GEAR THREADS RANGE | 0.5 - 120 (53 kinds) | mm |
| PITCH THREADS RANGE | 1 - 28 (24 kinds) | in |
| LONGITUDINAL FEEDS RANGE | 0.1 - 24.3 | mm/rpm |
| CROSS FEEDS RANGE | 0.05 - 12.15 | mm/rpm |
| RAPID FEED: LONG./CROSS | 4000, 2000 | mm/min |
| TOOL POST | ||
| TOOL SECTION | 32 x 32 | mm |
| CARRIAGE | ||
| MAX. TRAVEL OF CROSS SLIDE | 430 | mm |
| MAX. TRAVEL OF COMPOUND SLIDE | 200 | mm |
| TAILSTOCK | ||
| TAILSTOCK SLEEVE DIA. | 120 | mm |
| TAILSTOCK SLEEVE TAPER | MT6 | |
| MAX. TRAVEL OF TAILSTOCK | 240 | mm |
| MOTOR | ||
| MAIN MOTOR | 11 | KW |
| RAPID FEED MOTOR | 1.1 | KW |
| PACKING INFO | ||
| OVERALL SISE (DBC 2000mm) | 4600 x 1700 x 2100 | mm |
| N.W./G.W. (approximately) | 4.4/4.6 | ton |
