| Nombre | Especificaciones Técnicas | Unidad |
| TABLE SIXE | 360 x 1600 | mm |
| T SLOTS (N x W x D) | 3 x 18 x 80 | mm |
| TABLE LOAD-BEARING | 550 | kg |
| LONGITUDINAL TRAVEL (MANUAL/POWER) X | 1020/1000 | mm |
| CROSS TRAVEL (MANUAL/POWER) Y | 300/280 | mm |
| VERTICAL TRAVEL (MANUAL/POWER) Z | 410/400 | mm |
| FEED SPEED STEPS | 18 | steps |
| FEED SPEED RANGES: LONGITUDINAL X | 15 - 750 | mm/min |
| CROSS Y | 15 - 750 | mm/min |
| VERTICAL Z | 5.7 - 280 | mm/min |
| RAPID SPEED RANGES: LONGITUDINAL X | 2250 | mm/min |
| CROSS Y | 2250 | mm/min |
| VERTICAL Z | 844 | mm/min |
| DISTANCE BETWEEN TABLE CENTER TO VERTICAL GUIDE WAY | 235 - 535 | mm |
| ARBOR DIAMETER | ɸ32 ɸ40 | mm |
| MIN. DISTANCE FROM SPINDLE NOSE TO TABLE | 60-460 | mm |
| SPINDLE QUILL TRAVEL | 75 | mm |
| DISTANCE BETWEEN VERTICAL GUIDE WAY TO SPINDLE CENTER | 380 | mm |
| MAX. ROTARY ANGLE OF THE VERTICAL MILLING HEAD | ±45° | |
| SPINDLE HOLE TAPER | 7:24 NO:50 | |
| DIAMETER OF SPINDLE HOLE | ɸ29 | mm |
| SPINDLE SPEED STEPS | 18 | steps |
| SPINDLE SPEED RANGES | 30 - 1500 | r/min |
| MAIN MOTOR POWER | 7.5 | kw |
| FEED MOTOR POWER | 1.5 | kw |
| OVERALL SIZE | 2307 x 2028 x 2096 | mm |
| NET WEIGHT | 3300 | kg |
