| Nombre | Especificaciones Técnicas | Unidad |
| NOMINAL PRESSURE | 2500 | kn |
| USABLE LENGTH | 3200 | mm |
| DISTANCE BETWEEN UPRIGHTS | 2500 | mm |
| BREAKING STRENGTH FOR PLATE | 450 | N/mm2 |
| THROAT DEPTH | 350 | mm |
| RAM STROKE | 250 | mm |
| MAX. OPENING HEIGHT | 520 | mm |
| MAIN MOTOR POWER | 15 | kw |
| RANGE OF BACK GAUGE | 20 - 600 | mm |
| POSITION PRECISION OF BACK GAUGE | ± 0.5 | mm |
| REPEATABILITY OF BACK GAUGE | ± 0.5 | mm |
| RAM SPEED RANGE RAPID DOWN | 70 | mm/s |
| RAM SPEED RANGE RUN | 7 | mm/s |
| RAM SPEED RANGE RETURN | 70 | mm/s |
